A gutter is a concave part between the two spans of a building’s roof, used for organized drainage to collect rainwater and discharge it to the ground through vertical pipes. Divided by location, it is divided into inner gutter (inside the outer wall) and outer gutter (outside the wall).
A gutter is a concave part between the two spans of a building’s roof, used for organized drainage to collect rainwater and discharge it to the ground through vertical pipes. Divided by location, it is divided into inner gutter (inside the outer wall) and outer gutter (outside the wall).
The material of the gutter includes galvanized sheet and aluminum alloy
Metal gutters are suitable for large-scale projects such as commercial complexes due to their strong corrosion resistance
Key points for selecting a Hebei Liming Metal Gutter Forming Machineโ
Power and efficiency: The rated power needs to match the production demand (such as 7.5W or 5.5W), and the molding speed affects the output (such as 8-14m/min).
Processing capability: Pressing thickness range (such as 0.3-3mm), can process materials (galvanized sheet, stainless steel).
Automation level: Fully automatic hydraulic cutting and CNC system can improve accuracy.
Customized services for Hebei Liming Metal Gutter Forming Machine
Clearly define requirements (such as gutter size and material), select manufacturers that support customization, and ensure that the equipment matches production requirements.
After sales support for Hebei Liming Metal Gutter Forming Machine
Prioritize choosing brands that provide technical guidance and quick response (such as within 24 hours), and confirm warranty terms.
Quality judgment method for Hebei Liming Metal Gutter Forming Machine
Parameter verification: Compare the nominal parameters of the device (such as power and accuracy) with the actual requirements to see if they match.
Brand reputation: refer to transaction volume and user reviews.
Field testing: It is required to test the machine and check the smoothness and dimensional stability of the formed parts.
By integrating core parameters, brand services, and after-sales support, high cost-effective gutter forming machines can be effectively selected.
|
Name
|
Gutter Roll Forming Making Machine
|
|
|
Raw Material
|
Material
|
Aluminium PPGI PPGL GI GL
|
|
Width
|
914/925/1000/1200/1220/1250/1260mm
|
|
|
Thickness
|
0.3-0.8mm, customized
|
|
|
Power Required
|
Power
|
380V 3Phase 50Hz, customized
|
|
Cutting Motor
|
5.5KW, Lichao, Shanghai/Siemens Brand
|
|
|
Roll Forming Machine
|
Support Frame
|
350H steel, 10mm
|
|
Forming Station
|
16 rows, exactly according to profile drawing
|
|
|
Structure
|
16mm
|
|
|
Shaft
|
45# high grade steel, 70mm, solid, with keyway
|
|
|
Roller
|
45# high grade steel with heat treatment, hard chrome plated
|
|
|
Chain
|
1.0inch
|
|
|
Bearing
|
Standard
|
|
|
Speed
|
12-18m/min
|
|
|
Electric Components
|
Delta / Siemens / Mitsubishi
|
|
|
Cutting Blade
|
Cr12Mov, quenched 58ยฐ-62ยฐ
|
|
|
Operation
|
Touch Screen
|
|
|
Dimension
|
8.5*1.5*1.4M
|
|
|
Weight
|
6.0T
|
|
1. A machine doesn't just provide a few photos to prove what they can produce
2. A machine should have a complete production and assembly system photos and videos. When choosing a company with a factory, it is necessary to ensure that the company has a complete after-sales service system.
Our company's engineers have studied in well-known European cold bending companies and have great advantages in machine design and R&D and manufacturing.
Generally speaking, the machine takes about 40 days to complete, if you need a machine urgently, we can make it urgently, because I have a large number of spare parts.
Because we insist that every factory should put quality first, we make the machines more automated, more reliable and accurate, and have a longer service life.
The equipment can be used for nearly 20 years, and we provide lifetime after-sales service.
Product quality is the ultimate, the biggest after-sales service is service, 26 years of production experience, to be a service company that you have the strength to guarantee
1. Give me the dimension drawing and thickness, it is very important.
2. If you have requirements for production speed, power, voltage and brand, please explain in advance.
3. If you don't have your own outline drawing, we can recommend some models according to your local market standard.
