Roof Snap Lock Standing Seam Panel Roll Forming Machine

Hebei Liming Peruvian Market Tr4 Tr5 Double Layer Roll Forming Machine

A TR4 TR5 machine refers to a type of cold roll forming machine used to manufacture metal roofing sheets, specifically creating TR4 and TR5 profiles (Trapezoidal Roof profile 4 and 5), which are popular for industrial and residential buildings due to their strength and aesthetic appeal, often forming double layers (TR4/TR5) for efficiency in a single machine. These machines take flat steel coils, feed them through a series of rollers to shape them into the desired corrugated or trapezoidal pattern, and then automatically cut them to length, all controlled by PLC systems.

Chat Now

Product Video

Product Details

Key Features & Components

Rollers: Precision-engineered rollers (often hardened steel like Cr12) form the profile.
Uncoiler: Holds and unwinds the steel coil.
Feeding & Forming Stations: Multiple stations progressively shape the metal.
Cutting System: Hydraulic or mechanical cutter to size the finished sheets.
Control Panel: Touchscreen (HMI) with PLC (Programmable Logic Controller) for automation and easy operation.
Double Layer: Many modern TR4 TR5 machines are double-layer, producing two different profiles (like TR4 and TR5) simultaneously from one machine.

Applications

Factories, warehouses, hotels, and mobile homes.
Residential and commercial buildings.

Benefits

Efficiency: Double-layer models produce two types of tiles at once.
Accuracy: PLC control ensures consistent, precise profiles.
Durability: Robust construction with hardened rollers for long life.

In essence, it’s a specialized industrial machine for creating durable, profiled metal roofing panels.

Product Parameters

NO.	Item	Specification
Material	Raw material	Galvanized steel or PPGI
Material	Thickness	0.3mm—0.8 mm
Decoiler	Operation	Manual or Hydraulic
Decoiler	Weight capacity	3T 5T 7T 10T
Machine	Roller station	14-22 or depend on customer’ drawing
	Shaft diameter	70mm—80 mm
	Machine body frame	350H steel
	Roller material	Cr12
	Machine size	About 61.51.2 m
	Machine weight	4 – 6 tons
	Machine color	As customer need
	Working speed	12-60 m/min
Cutter	Hardness	50-65 HRC
	Cutting tolerance	± 1mm
	Material	Cr12
	Operate	Hydraulic cutting
Power	Main motor	7.5 KW
	Pump motor for cutter	5.5 KW
	Voltage	380V/50HZ, 3P or Customized as customer’ request
